Troubleshooting Network Issues with Packet Captures

Packet captures are the most powerful diagnostic tool in networking. Here is a systematic approach to using them effectively for real troubleshooting.

When to Reach for Packet Captures

Use packet captures when layer 2-4 problems are not obvious from interface statistics and logs. Common scenarios: unexplained TCP retransmissions, connection resets, intermittent connectivity, suspected firewall misconfigurations, and application performance issues where the application team blames the network.

Capturing in the Right Place

The most common mistake is capturing in the wrong place. To diagnose a problem, you need captures on both sides of the suspected failure point:

• Client-side capture shows what the client sent and received
• Server-side capture shows what the server sent and received
• A mismatch between them tells you where packets are being dropped or modified

For a firewall issue, capture on both the inside and outside interfaces simultaneously.

Filtering Effectively

Capturing everything is usually too much data. Use display filters in Wireshark to focus on what matters:

# Filter to a specific host
ip.addr == 192.168.1.100

# Show only TCP problems
tcp.analysis.flags && !tcp.analysis.ack

# Show DNS traffic
dns

# Show TLS handshakes
ssl.handshake

# Show HTTP requests
http.request

What to Look For

TCP retransmissions: The sender is not receiving acknowledgments. Usually indicates packet loss.

TCP resets (RST): An abrupt connection termination. Could be a firewall blocking mid-session, a crashed service, or a NAT timeout.

ICMP unreachable messages: The return path might be failing while the forward path works.

Time deltas: In the time column, large deltas before a packet indicate delay at the sending side. Large deltas before an ACK indicate delay at the receiving side.

Window size zero: The receiver's buffer is full. Application is not reading data fast enough.

Capturing on Linux

# Capture on eth0 to a file
tcpdump -i eth0 -w capture.pcap host 192.168.1.100

# Rotate files every 100MB, keep 10 files
tcpdump -i eth0 -w capture.pcap -C 100 -W 10
